Display Size

2560 X   1600

Line Rate

Max.10.8Gbps(2.7GHz-1,2,4Lanes/1.6GHz-1,2,4Lanes)

Output Format

RGB444,YCbCr444(8,10Bit)/YCbCr422(8,10,12Bit)

Compliant

Displayport   1.1aVersion

Audio

SPDIF,192KHz,2   Channels

Vertical

10~300Hz   / 1 Line Resolution

Pixel Clock

8~330MHz

Video Level

R,G,B(Load   75 ohm,0~1.0V Programmable)

Output Connector

15P   D-Sub,DVI-I

EDID

Read

Separate Sync

HS,VS(3.0V~5.5Vp-p   Programmable / Inherited Sync Level is 4.8Vp-p)

Transfer Type

*Single   TMDS 24 Bit Input Mode / *Dual TMDS 12 Bit Input Mode

EDID

Read

HDCP

Support   Single & Dual

Compliant

DVI   1.0 Support

Video Signal Type

RGB

Output Connector

DVI-I(DVI   2Ports,Single/Dual)

Data Bit

8~16   Bit

Time

480i/p(59.94Hz),576i/p(50Hz),720p(59.94/60Hz),1080i/p(50/59.94/60Hz)   1080p(24/25/30/50/59.94/60Hz)for ATSC and DVB Format

Separate Sync

50~400mV   Programmable

*NTSC443(4.4MHz)

*PAL   B,D,G,H,I(4.434MHz)

*SECAM(For=4.406MHz/For=4.25MHz)

Subcarrier Stability

25ppm(±25Hz/ 1MHz)

Video Output

Composite(BNC),S-Video

*Signal:CVBS(Connector:BNC)

*Signal:Y/C(Connector:4Pin-Mini   Din)

Closed Caption(NTSC)

C1,C2,C3,C4/T1,T2,T3,T4

V-Chip

*MPAA   Rating:G,PG,PG-13,R,NC-17,X

*FCC   Rating:TV-Y,TV-Y7,TV-G,TV-PG,TV-14,TV-MA

Teletext(PAL)

Teletext   System B Level 1,1.5

Separate Sync

1~318mV   Programmable

Pixel Rate Range

25~165MHz（TMDS Clock：25~225MHz）/  4K x 2K(293MHz)

Standard Spec

EIA/CEA-861E

Video Siganl Type

RGB,YCbCr

Pixel Encoding

RGB444，YCbCr444，YCbCr422

Data bit of RGB & YCbCr

8,10,12(RGB&YCbCr)

Color Space

RGB,BT-601,BT-709,xvYCC-601,xvYCC-709

HDCP

Support   HDCP 1.2 Version

EDID

Read

Output Connector

Type   A,HDMI 5 Port(ARC 3Port,4K x 2K Port)

Note

Audio   Return Channel(ARC)3 Port

3D   Video Formats(Frame Packing, Side by Side,Top &Bottom,Field Alternative)

4K x   2K Video fomats 2Port

Number of Channel

8   Channels

Bit per Sample

24

Waveform

Sine   Wave

Frequency Range

20Hz   to 20KHz/5Hz step

Level Range

0dB to   -110dB/0.5dB step

External Audio Input

Optical,Optical

Special Control Mode

Fix,Sweep,Swap,Optical,Mute

Level Range

0mV rms   to 900mVrms/5mV rms

Waveform

Sine   Wave

Number of Channel

2   Channels

Connector

RCA

Special Control Mode

Fix,Sweep,Swap,Mute

Function Storage

99Group(1Group;32Step)

Data Storage

Device

Timing

999Timing(User:1~500,Default:501~999)

Pattern

999Pattern(Uset:1~500,Default:501~999)

Operating Conditions

*Temperature:0~40

*80%Humidity,Non-condensing

Dimension(WXDXH)

440X355X145mm,Weight:6Kg

User Interface

*Front   Panel(6.4 inch/Graphic LCD)Key Pad

*Possible   to Timing Parameter Edit

*USB,RS-232C,PC   EDIT Tool
